DotSoft Word2CAD

Free Download DotSoft Word2CAD full version standalone offline installer for Windows, it can easily convert Word documents into CAD format.

Overview of DotSoft Word2CAD

It overcomes the limits and problems associated with OLE placement of Microsoft Word documents into AutoCAD, BricsCAD and IntelliCAD.В It draws the document using native geometry so the result is a bound collection of mtext (& table) objects that is linked to original document, can be plotted without problems & is highly portable to other users.

Features of DotSoft Word2CAD

• Automatically updates changed Word documents on drawing open
• Uses bookmarks, allowing the area to grow/shrink as you to add/remove paragraphs
• Exclusive column wrapping. Users can specify the maximum column height and gap distance. The results will
• flow to the designated height, then move up and to the right to continue until done
• Style settings. This allows multiple styles to be defined and chosen during placement. Results automatically
• take on changed style parameters when updated. Style files can be shared and administered
• Quickly scan a project folder (or an entire drive) for drawings that need updating, then process them in
• batch, unattended
• Runs as true 64bit application in supported CAD engine

Technical Details and System Requirements

• Supported OS: Windows 7/8/10
• Processor: Pentium IV or higher
• RAM: 1 GB RAM (2 GB recommended)
• Free Hard Disk Space: 200 MB or more
